how to remove center console [56k?]

i'm currently working on making my interior black and gray. i did my door panels a little over a month ago, along with the dash pieces. most recently i decided to do the top portion of my center console as well. those pieces are extremely easy to remove so if you're not 100% sure how to do it then read on.

first step is to remove the emergency brake panel. in this above shot you can see the completed panel.

Click the image to open in full size.

there are 6 clips to this thing. one in each corner and two in the center. all you have to do is lift up at the corners [i started at the front of one side and just worked my way around]

btw, you will need to lift the e-brake in order to slide this piece off.

then you will be left with this...

Click the image to open in full size.

if you want to paint the brake handle as well, there will be a little clip on the underside that you just have to push in and the plastic piece will slide right off. warning...i used a little primer on mine and a lot of clear coat but it still has a few but barely visible scratches.

anyway, the rear cup holders. there are 5 clips to this one but unlike the e-brake panel, this one is easier to remove by lifting up from the back and then working your way around. i dunno why i bothered with this pic but here's a shot of the two front clips...

Click the image to open in full size.

after a little lifting you'll be left with this ugly mug...

Click the image to open in full size.

after that, the panel around the shifter. this one is a little tougher to get out. i took the cup holders out when i did mine so i could kinda see what was going on down there

Click the image to open in full size.

if you chose to do that great, but in order to remove the panel you must first put the car in neutral or any gear after that really as long as the shifter is out of the way.

Click the image to open in full size.

i didn't get a shot of this panel removed because my batteries died [r.i.p] but all you have to do here is pull up on the corners closest to the e-brake and work your way around [if i remember correctly there are 8 clips]. after all the clips have let loose you'll have to undo the power outlet clips but don't pull the panel out too far to do that because the wires to the outlets are rather short. at least mine are but once that is done pull the panel back and lift it out. pat yourself on the back because you are done! to put everything back in obviously just reverse the steps. oh, i absolutely could not get those power outlets out of the panel so you'll have to tape those off if you don't want paint getting on them. here are some before and after shots of my car, i like how everything has turned out so far...


Click the image to open in full size.

Click the image to open in full size.

one more thing, my choice of paint was krylon fusion satin black
__________________

East Coast Cobalts: NY | Northern NY Cobalt Concepts
-Traded Away 1.13.14

Last edited by TommyP; 05-17-2012 at 09:05 PM.
spiderbite is offline   Reply With Quote
Old 10-25-2007, 07:22 PM   #2
The Stig
Points: 24,490, Level: 95
Points: 24,490, Level: 95 Points: 24,490, Level: 95 Points: 24,490, Level: 95
Level up: 14%, 860 Points needed
Level up: 14% Level up: 14% Level up: 14%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


MarcS's Avatar

Join Date: 05-11-05
Location: New York
Member #: 1770
Posts: 6,482
Images: 4
iTrader: (0)
Send a message via AIM to MarcS Send a message via MSN to MarcS
sleepyweaselski
Check out my gallery

Approved
__________________
2005 Arrival Blue Cobalt SS
Injen CAI, Intense 3" Pulley, Ingalls ETD
>>Please Read Forum Rules<<

...When it absolutely, positively, has to be destroyed over nite.
MarcS is offline   Reply With Quote
Old 10-25-2007, 11:30 PM   #3
Senior Member

Points: 35,901, Level: 100
Points: 35,901, Level: 100 Points: 35,901, Level: 100 Points: 35,901, Level: 100
Level up: 0%, 0 Points needed
Level up: 0% Level up: 0% Level up: 0%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%

Award-Showcase

Join Date: 02-21-07
Location: Calgary, Alberta
Member #: 14339
Posts: 16,180
Images: 17
iTrader: (0)
outtamymind85
Check out my gallery

very nice write up dude. i would add a few pics of a 5speed as it's a little differen't in taking the main center console out. you have to put the shifter into 1st and you have to pull the ebrake up. as well as you have to unhook the shifter boot. but ya very nice write up.
__________________
outtamymind is offline   Reply With Quote
Old 10-26-2007, 05:28 PM   #4
Junior Member

Points: 6,870, Level: 54
Points: 6,870, Level: 54 Points: 6,870, Level: 54 Points: 6,870, Level: 54
Level up: 60%, 80 Points needed
Level up: 60% Level up: 60% Level up: 60%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-29-07
Location: new york
Member #: 20348
Posts: 468
Images: 21
iTrader: (0)
Check out my gallery

thanks
__________________

East Coast Cobalts: NY | Northern NY Cobalt Concepts
-Traded Away 1.13.14
spiderbite is offline   Reply With Quote
Old 10-26-2007, 05:31 PM   #5
Senior Member

Points: 11,901, Level: 71
Points: 11,901, Level: 71 Points: 11,901, Level: 71 Points: 11,901, Level: 71
Level up: 63%, 149 Points needed
Level up: 63% Level up: 63% Level up: 63%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 05-21-06
Location: Gainesville, FL
Member #: 7445
Posts: 5,584
Images: 109
iTrader: (0)
Send a message via AIM to joeworkstoohard
Joeworkstoohard Joeworkstoohard
Check out my gallery

small suggestion... i'd hit that with a few coats of a non gloss clear.
__________________
Mods: some different headlights... uhhh... and a shorty antenna... i should be keeping up with SS/SCs now.

Kills: 90 camry with a compression problem on #5, 2006 Peterbilt (no trailer even), 2007 Shelby Mustang

joeworkstoohard is offline   Reply With Quote
Old 10-26-2007, 09:20 PM   #6
Junior Member

Points: 6,870, Level: 54
Points: 6,870, Level: 54 Points: 6,870, Level: 54 Points: 6,870, Level: 54
Level up: 60%, 80 Points needed
Level up: 60% Level up: 60% Level up: 60%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-29-07
Location: new york
Member #: 20348
Posts: 468
Images: 21
iTrader: (0)
Check out my gallery

it's really not that glossy, the flash from the camera made it seem that way.
__________________

East Coast Cobalts: NY | Northern NY Cobalt Concepts
-Traded Away 1.13.14
spiderbite is offline   Reply With Quote
Old 11-02-2007, 06:16 AM   #7
Senior Member

Points: 39,258, Level: 100
Points: 39,258, Level: 100 Points: 39,258, Level: 100 Points: 39,258, Level: 100
Level up: 0%, 0 Points needed
Level up: 0% Level up: 0% Level up: 0%
Activity: 13.7%
Activity: 13.7% Activity: 13.7% Activity: 13.7%

Award-Showcase

Join Date: 09-03-06
Location: Las Cruces, NM
Member #: 10015
Posts: 18,720
Images: 312
iTrader: (5)
EmperorJJ3
Check out my gallery

Quote:
Originally Posted by outtamymind View Post
very nice write up dude. i would add a few pics of a 5speed as it's a little differen't in taking the main center console out. you have to put the shifter into 1st and you have to pull the ebrake up. as well as you have to unhook the shifter boot. but ya very nice write up.
how do u remove shifter boot?
__________________

My Sale Refs Dual Alternator Setup Carbon Fiber Door Pods


Quote:
Originally Posted by dragon daddy
My advice: If you are serious about reducing noise in the vehicle, use Second Skin products. If not, don't spend the money and add the weight and turn you music up a little louder.
EmperorJJ1 is offline   Reply With Quote
Old 11-02-2007, 06:18 AM   #8
Original Hayden Fanatic

Points: 104,050, Level: 100
Points: 104,050, Level: 100 Points: 104,050, Level: 100 Points: 104,050, Level: 100
Level up: 0%, 0 Points needed
Level up: 0% Level up: 0% Level up: 0%
Activity: 0.3%
Activity: 0.3% Activity: 0.3% Activity: 0.3%

Award-Showcase

REIGN SS's Avatar

Join Date: 05-06-06
Location: Dayton, O HI O
Member #: 7110
Posts: 33,179
Images: 93
iTrader: (0)
REIGN SS
Check out my gallery

Quote:
Originally Posted by EmperorJJ1 View Post
how do u remove shifter boot?
around the base there should be a section at the top that you can push in, then pull it up....
__________________
REIGN SS is offline   Reply With Quote
Old 12-09-2011, 10:35 PM   #9
Senior Member

Points: 4,867, Level: 44
Points: 4,867, Level: 44 Points: 4,867, Level: 44 Points: 4,867, Level: 44
Level up: 59%, 83 Points needed
Level up: 59% Level up: 59% Level up: 59%
Activity: 0.6%
Activity: 0.6% Activity: 0.6% Activity: 0.6%


Join Date: 01-08-11
Location: north of milw, wi
Member #: 58220
Posts: 1,097
iTrader: (0)
Check out my gallery

subd
