Sway bar bushings

i was wondering if any one else has this problem wih there sway bar bushings i have went thourgh to sets now and dont no y is there any polyurthane ones i can buy some one please help
richienolan is offline   Reply With Quote
Old 04-11-2010, 03:03 AM   #2
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

darn nobody knows y im going thourgh these bushings or were i can find some good polyurthan ones at
richienolan is offline   Reply With Quote
Old 04-14-2010, 07:10 AM   #3
New Member

Points: 2,104, Level: 27
Points: 2,104, Level: 27 Points: 2,104, Level: 27 Points: 2,104, Level: 27
Level up: 70%, 46 Points needed
Level up: 70% Level up: 70% Level up: 70%
Activity: 1.6%
Activity: 1.6% Activity: 1.6% Activity: 1.6%


Join Date: 12-07-09
Location: Riverview,Fl
Member #: 51922
Posts: 199
iTrader: (0)
Check out my gallery

try energy suspension, don't know how they look but if you know the measure, you can get it from them. and remember to keep an eye on the sway bar end links, i think because of the stiffness of the sway bar, does will receive a beat. my 2 cents, then again i could just be wrong 100%.
__________________
This is my signature you FOOL
PARTS FOR SALE
http://www.cobaltss.net/forums/parts...7/#post6168796
Front stance coilovers for ss/sc or ss/tc $485 shipped 48 states.
Pm me if interested.
this-is-it-ss-05 is offline   Reply With Quote
Old 04-14-2010, 10:02 AM   #4
Senior Member
Points: 7,665, Level: 58
Points: 7,665, Level: 58 Points: 7,665, Level: 58 Points: 7,665, Level: 58
Level up: 58%, 85 Points needed
Level up: 58% Level up: 58% Level up: 58%
Activity: 0.2%
Activity: 0.2% Activity: 0.2% Activity: 0.2%


Join Date: 02-03-08
Location: Port Perry Ontario
Member #: 22963
Posts: 3,454
Images: 20
iTrader: (0)
Check out my gallery

#1 there are no poly bushings and it would be a step back. #2 you are probably single bolt and tab fixing and that is the problem. Go to updated FE5 two bolt clamps your problems are over. I think....
qwikredline is offline   Reply With Quote
Old 04-14-2010, 11:03 AM   #5
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

no i do have the two bolt clamp and my sway bar links are good and y would poly ones be taking a step back im a little confused
richienolan is offline   Reply With Quote
Old 04-14-2010, 11:31 AM   #6
OBZ
Senior Member

Points: 7,805, Level: 59
Points: 7,805, Level: 59 Points: 7,805, Level: 59 Points: 7,805, Level: 59
Level up: 28%, 145 Points needed
Level up: 28% Level up: 28% Level up: 28%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 11-07-07
Location: SL,UT
Member #: 21227
Posts: 1,014
iTrader: (0)
Check out my gallery

polyurethane is actually a softer material than OEM bushings..
__________________
2006 Cobalt LT - Rally yellow - Fully bolted , tuned, suspended - Totaled
2009 Cobalt SS Sedan - G85 - White
OBZ is offline   Reply With Quote
Old 04-14-2010, 12:00 PM   #7
Senior Member

Points: 15,953, Level: 81
Points: 15,953, Level: 81 Points: 15,953, Level: 81 Points: 15,953, Level: 81
Level up: 21%, 397 Points needed
Level up: 21% Level up: 21% Level up: 21%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 06-07-06
Location: Minnesota
Member #: 7834
Posts: 13,602
Images: 8
iTrader: (1)
Check out my gallery

do you have an upgraded sway bar? what model cobalt are you?
__________________

2009 Cobalt SS
northvibe is offline   Reply With Quote
Old 04-14-2010, 01:10 PM   #8
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

no stock everything 2006 ss/sc ok so i think im just going to get the stock bushings
richienolan is offline   Reply With Quote
Old 04-14-2010, 02:03 PM   #9
Senior Member

Points: 15,953, Level: 81
Points: 15,953, Level: 81 Points: 15,953, Level: 81 Points: 15,953, Level: 81
Level up: 21%, 397 Points needed
Level up: 21% Level up: 21% Level up: 21%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 06-07-06
Location: Minnesota
Member #: 7834
Posts: 13,602
Images: 8
iTrader: (1)
Check out my gallery

...what other mods do you have? do you have like a engine damper? or motor mounts? seems odd you would go threw sway bar bushings like that. What do you mean you go threw them? Like are they just squeaking or are they destroyed?
__________________

2009 Cobalt SS
northvibe is offline   Reply With Quote
Old 04-14-2010, 02:36 PM   #10
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

no other mods yet but i have ordered damper and mounts but yeah the stock ones were good till a couple of months ago and started goign bad and now they are destroyed so i replaced them with top of the line moogs and they only lasted 1 month and are destroyed so i think im goin back to stock ones
richienolan is offline   Reply With Quote
Old 04-14-2010, 02:38 PM   #11
Senior Member

Points: 15,953, Level: 81
Points: 15,953, Level: 81 Points: 15,953, Level: 81 Points: 15,953, Level: 81
Level up: 21%, 397 Points needed
Level up: 21% Level up: 21% Level up: 21%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 06-07-06
Location: Minnesota
Member #: 7834
Posts: 13,602
Images: 8
iTrader: (1)
Check out my gallery

hmmm how many miles on your car? do you drive it hard?

well see if the moogs have a warranty on them, but yeah go with stock ones again.
__________________

2009 Cobalt SS
northvibe is offline   Reply With Quote
Old 04-14-2010, 05:59 PM   #12
ecl
New Member
Points: 4,432, Level: 42
Points: 4,432, Level: 42 Points: 4,432, Level: 42 Points: 4,432, Level: 42
Level up: 41%, 118 Points needed
Level up: 41% Level up: 41% Level up: 41%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-19-08
Location: Elko Nevada
Member #: 29817
Posts: 29
iTrader: (0)
Check out my gallery

this is actually a very common thing over on the HHR forums. Ive had it since around 20k miles and been to the dealer countless times to get fixed with no luck. I got a pair of greasable bushings which unfortunatly I havent got put on yet, but hopefully soon. Also another part in question is the end links(Im pretty sure thats what I read some were).
__________________

08 Chevy HHR Half Panel
Black Chrome, TTR sway bar, stubby antenna
ecl is offline   Reply With Quote
Old 04-14-2010, 11:48 PM   #13
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

yeah i got 47k on her the problem started at about 45k with the old ones and i know my end links are good i dont drive it hard all the time lol but i do live in cleveland and the roads up here suck *****, i just moved up here from morganown, WV and thats about the tim all this happened so im saying its ohio's fault lol
richienolan is offline   Reply With Quote
Old 04-15-2010, 10:43 AM   #14
Senior Member
Points: 7,665, Level: 58
Points: 7,665, Level: 58 Points: 7,665, Level: 58 Points: 7,665, Level: 58
Level up: 58%, 85 Points needed
Level up: 58% Level up: 58% Level up: 58%
Activity: 0.2%
Activity: 0.2% Activity: 0.2% Activity: 0.2%


Join Date: 02-03-08
Location: Port Perry Ontario
Member #: 22963
Posts: 3,454
Images: 20
iTrader: (0)
Check out my gallery

Its a mystery to me. I hammer the heck out of the car, we been road racing Delta's steady since 2004 & dont see the bushings work out on a 2 bolt clamp...dont know what to tell you...
qwikredline is offline   Reply With Quote
Old 04-15-2010, 10:45 AM   #15
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

well thanks any ways lol
richienolan is offline   Reply With Quote
Old 04-15-2010, 10:58 AM   #16
Senior Member
Points: 7,665, Level: 58
Points: 7,665, Level: 58 Points: 7,665, Level: 58 Points: 7,665, Level: 58
Level up: 58%, 85 Points needed
Level up: 58% Level up: 58% Level up: 58%
Activity: 0.2%
Activity: 0.2% Activity: 0.2% Activity: 0.2%


Join Date: 02-03-08
Location: Port Perry Ontario
Member #: 22963
Posts: 3,454
Images: 20
iTrader: (0)
Check out my gallery

Quote:
Originally Posted by richienolan View Post
well thanks any ways lol
Click the image to open in full size.
Here is my problem: look at the retaining clip. it has a stamped groove in the clamp and it has rolled edges;all help retain the swaybar bushing in place, plus a bonded stop in the bar itself. The bushing has to do some pretty extraordinary things to move out. Over 5 years and about 25 race cobalts we have never seen this bushing "walk" out. Just sayin'

P.S. This cradle is out of my car, an original one bolt with tab mount cradle converted with the new style FE5 clamp and a hole drilled with a bolt to update it..
qwikredline is offline   Reply With Quote
Old 04-16-2010, 12:59 PM   #17
Member
Points: 5,086, Level: 45
Points: 5,086, Level: 45 Points: 5,086, Level: 45 Points: 5,086, Level: 45
Level up: 68%, 64 Points needed
Level up: 68% Level up: 68% Level up: 68%
Activity: 0%
Activity: 0% Activity: 0% Activity: 0%


Join Date: 09-21-09
Location: Arthurdale ,Wv
Member #: 50458
Posts: 399
Images: 14
iTrader: (0)
Check out my gallery

my bar just moves up in down not side to side and mne looks different then that cuz my smaller bolt comes up thurgh the bottom and has a nut on the top but that should not really matter
richienolan is offline   Reply With Quote
Old 06-27-2013, 02:34 PM   #18
Premium Member
Points: 8,135, Level: 60
Points: 8,135, Level: 60 Points: 8,135, Level: 60 Points: 8,135, Level: 60
Level up: 93%, 15 Points needed
Level up: 93% Level up: 93% Level up: 93%
Activity: 0.5%
Activity: 0.5% Activity: 0.5% Activity: 0.5%


Join Date: 07-23-07
Location: Neapolis, Oh
Member #: 18473
Posts: 584
Images: 11
iTrader: (1)
Check out my gallery

Is the 1 bolt factory and the 2 bolt is an update to the factory ss/sc clamp? A factory ss/sc car would need which clamp and the 24mm bushing correct?
Hobbitjones is offline   Reply With Quote
Old 06-27-2013, 02:34 PM
CobaltSS
Chevy Cobalt




Paid Advertisement



Reply

Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On



All times are GMT -4. The time now is 08:03 AM.


vBulletin copyright ©2000 - 2014, Jelsoft Enterprises Ltd.
Admincp backup
