Wastegate rod adjustment help

I removed turbo and removed wastegate actuator. I cannot seem to find the sweet spot on where to adjust it to. I was running about 20-21lbs boost on stock adjustment, can anybody post a picture or take a thread count as to where i need to be at to get back stock? I am not getting boost or getting 5lbs really quick and cutting out.
Reply
Old Aug 23, 2020 | 02:57 AM
  #2
cw383's Avatar
Senior Member
iTrader: (6)

Joined: 03-27-11
Posts: 801
Likes: 28
From: butler,pa
..

A good starting point is to turn the nut until in contacts the wastegate arm with no slack, and then 2 full turns. I put some cross hatch marks with Dremel on the nut to easier reference the flat when I cranked it down. Its easy to lose track. Also you may need to grasp the rod with a small pair of vice grips to keep it from spinning.
Reply
Old Aug 24, 2020 | 02:28 AM
  #3
2010MurderSS's Avatar
Thread Starter
New Member

Joined: 07-16-19
Posts: 31
Likes: 2
From: Mississippi
I was WAY off

Originally Posted by cw383
A good starting point is to turn the nut until in contacts the wastegate arm with no slack, and then 2 full turns. I put some cross hatch marks with Dremel on the nut to easier reference the flat when I cranked it down. Its easy to lose track. Also you may need to grasp the rod with a small pair of vice grips to keep it from spinning.
Is this is about where it was set stock? Thats where i had it and id like to get it as close as i can to there. And a questions beside the point.
If i were to tighten it a little tighter than where i had it, what sort of difference would that make? Not that i plan to, ive just never messed with it before chra rebuild and im curious.



Reply
Old Aug 26, 2020 | 04:32 PM
  #4
cw383's Avatar
Senior Member
iTrader: (6)

Joined: 03-27-11
Posts: 801
Likes: 28
From: butler,pa
That is about where they are stock. Not a good idea to overtighten, it may bed the waste gate arm
